JBL CWT128-WH 2-WAY Full-range Crossfire Waveguide - White

JBL CWT128-WH 2-Way Full-Range Crossfire Waveguide – White

The CWT128-WH is a compact dual 8-inch 2-way loudspeaker engineered for wide-dispersion applications in installed sound and portable reinforcement setups. Its compact footprint and lightweight construction make it easy to position and rig in any studio monitoring or live recording environment, while the Crossfired Waveguide design delivers consistent coverage across the listening field. This is a professional-grade speaker that combines power and versatility without unnecessary bulk, making it an excellent choice for tracking, overdubs, and live-to-tape sessions.

Coverage & Dispersion for Studio Monitoring

The 160° × 60° coverage pattern ensures even sound distribution across wide horizontal planes with tighter vertical control, ideal for capturing accurate mixes in tracking rooms and control spaces. The Crossfired Waveguide optimizes high-frequency reproduction across that wide pattern, eliminating the dead zones typical of narrower designs and revealing clarity in vocal takes and instrument details.

Power & Output for Recording Sessions

Rated for 450W long-term program power (1800W peak), the CWT128-WH achieves 129 dB SPL at 1 meter, delivering clear, commanding output through tracking sessions and overdub work. The dual 8-inch low-frequency drivers and dual compression drivers ensure tight bass response and articulate midrange without compromise across the 96 Hz – 19 kHz (±3 dB) operating range, capturing the full frequency spectrum needed for critical studio work.

Key Features

• Extremely Wide Angle Coverage dual 8-inch 2-way loudspeaker system
• 160° × 60° coverage pattern for broad, even dispersion
• Frequency Response: 96 Hz – 19 kHz (±3 dB)
• Extended low-end response: 71 Hz – 20 kHz (-10 dB)
• Maximum SPL: 129 dB @ 1 meter
• System power rating: 450W long-term / 1800W peak
• 8 Ohm nominal impedance with passive crossover at 1.5 kHz
• Dual JBL 228J 8-inch drivers with edge-wound voice coils and dual 2408H-1 compression drivers
• 70V/100V transformer taps (110W, 55W, 28W options)
• White DuraFlex finish with 16-gauge powder-coated steel grille
• Compact dimensions: 31.94" W × 10.22" H × 11.84" D
• Net weight: 40.9 lb (18.6 kg)

The CWT128-WH delivers professional output and pattern control in a manageable, portable package suited to studios, control rooms, and session spaces where dependable wide-coverage monitoring is non-negotiable.
