JBL AW566-LS 15" HI-PWR ALL-WEATHER SPK W EN54-24, 60x60, GREY

JBL AW566-LS 15" High-Power All-Weather Speaker with EN54-24 Compliance

The AW566-LS is a sealed, weather-resistant loudspeaker built for studio-to-field recording and mobile production work. Its hand-laminated fiberglass construction and environmental durability make it ideal for capturing and monitoring audio in unpredictable conditions—from location recording sessions to outdoor mixing scenarios—while maintaining the acoustic clarity needed for professional production work.

Acoustic Performance & Coverage

This speaker delivers 90 dB sensitivity with a 60° × 60° coverage pattern, providing controlled, consistent sound projection across medium to large monitoring areas. The frequency response of 60 Hz–20 kHz supports full-range mixing and monitoring, with enough clarity for detail work and enough bass extension to evaluate low-end content during recording and post-production sessions.

Build Quality & Durability

Hand-laminated fiberglass construction with gray gelcoat and a heavily braced multilayer glass composite enclosure resists UV degradation and environmental stress. The 16-gauge powder-coated stainless steel grille with open-cell foam and mesh backing protects the drivers while maintaining acoustic transparency and corrosion resistance for field deployments and studio environments exposed to moisture or temperature fluctuations.

Key Features

• 2265H 15-inch low-frequency driver with dual voice coil and dual magnetic gap
• 2432H compression driver with 1.5-inch exit and 3-inch voice coil for high-frequency clarity
• 150W RMS power handling with 400W transformer for 70/100V line operation
• 8-ohm impedance for direct connection to amplifiers
• 60 Hz–20 kHz frequency response for full-range audio coverage
• 90 dB sensitivity for efficient sound projection
• EN 54-24 compliant for life-safety and emergency broadcast applications
• Sealed components on LS models prevent water and debris intrusion
• Vertical or horizontal mounting orientation for flexible installation
• Compact dimensions 22" × 14" × 12" with 24 lbs weight
• Stainless steel hardware throughout resists corrosion
• Hand-laminated fiberglass with gray gelcoat for UV stability

Engineered for remote sessions, outdoor tracking, and mobile mixing applications, the AW566-LS combines professional-grade drivers with sealed construction for reliable monitoring and reference listening in challenging acoustic environments where conventional studio speakers cannot perform.
