JBL AM5215/26-WH Two-way full range loudspeaker (white)

JBL AM5215/26-WH Two-way Full Range Loudspeaker

The AM5215/26-WH is a professional two-way loudspeaker engineered to deliver controlled, predictable coverage in studio monitor arrays, live tracking setups, and medium-scale venue installations. Built with heavy-duty construction and flexible rigging options, this white-finished cabinet maintains consistent acoustic behavior across diverse room configurations and mixing applications.

Acoustic Design & Coverage

A 380 mm (15-inch) low frequency driver with JBL's Differential Drive dual voice coil and dual magnetic gap pairs with a 38 mm (1.5-inch) compression driver routed through a Progressive Transition waveguide to maintain tight 120 x 60° coverage. The result is uniform sound distribution across the mixing plane with frequency response spanning 41 Hz to 18 kHz, providing the low-end extension and midrange clarity essential for accurate monitoring and recording work.

Cabinet Construction & System Integration

The enclosure uses multiply birch with heavy internal bracing, wrapped in JBL's DuraFlex finish for durability in both studio and live tracking environments. A 14 gauge steel grille with acoustically transparent foam lining protects the drivers, while 15 M10 threaded attachment points and a rotatable horn (vertical or horizontal orientation) enable precise placement in monitor arrays, isolation booths, and mobile recording setups.

Key Features

• 265H-1 380 mm (15 in) low frequency driver with Differential Drive dual voice coil and dual magnetic gap
• 2408H-1 38 mm (1.5 in) exit compression driver with 38 mm (1.5 in) voice coil
• Progressive Transition waveguide for controlled dispersion
• 120 x 60° coverage pattern
• Frequency response 41 Hz to 18 kHz
• Bi-amp/passive switchable operation
• NL4 Neutrik Speakon and CE-compliant barrier strip terminals
• Multiply birch enclosure with heavy internal bracing
• DuraFlex finish rated for indoor and outdoor use
• 14 gauge steel grille with acoustically transparent foam lining
• 15 M10 threaded rigging points
• Rotatable horn for flexible mounting orientation

The AM5215/26 combines professional-grade components with intelligent rigging infrastructure to anchor monitoring arrays in tracking rooms, support live mixing applications, or scale into multi-cabinet systems for larger sessions and productions.
